A Event Types for Alarms
This appendix describes the events that can be detected through the EPICenter Alarm System:
SNMP Trap Events on page 527
●
Configuring SNMP Trap Events on page 534
●
RMON Rising and Falling Trap Events on page 535
●
EPICenter Events on page 535
●
Many of the events defined below are standard traps applicable to all MIB-2 devices managed by the
EPICenter server. Extreme Networks proprietary traps are identified as such. For Extreme Networks
devices, the level of support in ExtremeWare and ExtremeXOS is also indicated.

SNMP Trap Events

Table 58: SNMP Trap Events
Event
Authentication Failed
BGP Backward
Transition
BGP Established
BGP M2 Max
Exceeded
BGP M2 Threshold
Reached
BGP Prefix Max
Exceeded
BGP Prefix Reached
Threshold
CPU Health Check
Failed
CPU Utilization Falling
Threshold
CPU Utilization Rising
Threshold
EPICenter Reference Guide
Definition
This trap indicates that a SNMP request with an invalid
community string is issued to the device.
This event is generated when the BGP FSM moves from a
higher numbered state to a lower numbered state.
This event is generated when the BGP FSM enters the
ESTABLISHED state.
Extreme Networks proprietary trap. Indicates that the number of
prefixes received over this peer session has reached the
maximum configured limit. (BGP4-V2)
Extreme Networks proprietary trap. Indicates that the number of
prefixes received over this peer session has reached the
threshold limit. (BGP4-V2)
Extreme Networks proprietary trap. Indicates that the number of
prefixes received over this peer session has reached the
maximum configured limit.
Extreme Networks proprietary trap. Indicates that the number of
prefixes received over this peer session has reached the
threshold limit.
Extreme Networks proprietary trap. Indicates that the CPU
Health Check has failed.
Extreme Networks proprietary trap. CPU Utilization Falling Trap
is generated when the extremeCpuAggregateUtilization falls
below 80% of the extremeCpuUtilRisingThreshold.
Extreme Networks proprietary trap. CPU Utilizations Rising trap
is generated when the value of extremeCpuAggregateUtilization
touches/crosses extremeCpuUtilRisingThreshold.
ExtremeWare/
ExtremeXOS
Version
ExtremeWare All/
ExtremeXOS 11.2
ExtremeWare 6.1.5
Not supported in
EXOS
ExtremeWare 6.1.5
Not supported in
EXOS
EXOS 10.1
EXOS 10.1
ExtremeWare 6.2.2
Not supported in
EXOS
ExtremeWare 6.2.2
Not supported in
EXOS
ExtremeWare 6.2
Not supported in
EXOS
ExtremeWare 6.2
Not supported in
EXOS
