View policy rules

View configured rules

Policy Rule Comparison

The Source Port QoS policy rule comparison display shows both the Ideal rules, as generated by the
EPICenter Policy Manager (shown in the left half of the table) and the Configured Rules as they exist on
the device, shown in the right half of the table.
The rows in the comparison display are displayed in colors that indicate the status of the rule:
Green The rule is a valid rule (is not in conflict with a rule already on the device), but that it
has not been configured on the device. Only the Ideal side of the table is filled in for
these rules.
White The rule is valid, and has been configured on the device. Both the Ideal and Configured
sides of the table are filled in.
Yellow The EPICenter-generated "ideal" rule conflicts with a rule already configured on the
device. Two rules conflict when the traffic patterns for the rule are the same but the
specified treatment (the QoS profile) is different. Both the Ideal and Configured sides of
the table are filled in.
Blue The rule is configured on the device, but it was not generated by the EPICenter Policy
Manager. Only the Configured side of the table is filled in for these rules.
The columns in the display show information as follows:
! (exclamation point) An empty column used to invoke a sort by policy precedence. Clicking the column
header will sort the policies in policy precedence order.
Policy Displays the name of the policy.
Ideal Source Port Displays the name of the device and the port specified by this policy.
Ideal Profile Indicates the QoS profile specified for port by this policy.
Config Source Port The device and port to which the QoS rule applies.
Config Rule Profile The QoS profile that applies to this port.
View Policy Rules
The Policy Rules display shows details of the Ideal Source Port QoS rules, as generated by the
EPICenter Policy Manager. The information in this display is as follows:
! (exclamation point) An empty column used to invoke a sort by policy precedence. Clicking the column
header will sort the policies in policy precedence order.
Policy Displays the name of the policy.
Source Port The device and port specified by this policy.
Profile The QoS profile that is specified for this VLAN by this policy.
To be used Indicates whether the rule is acceptable for configuration on the device (not in conflict
with any other rules). Values for this column are:
• Yes, the rule can be used.
• No (duplicated) indicating that the rule duplicates another rule.
• No (disabled) indicating that the policy is disabled.
EPICenter Reference Guide
Select to display the EPICenter rules only.
Select to display the configured rules only.
Source Port QoS Display
521
