To view the policies currently defined within the EPICenter Policy System, click the Policies radio
button just above the component tree. This displays a summary of the policies currently known to the
Policy Manager (see Figure
Figure 248: Policy View in the Policy Manager
The component tree on the left shows the policies defined through the Policy Manager. The main applet
frame shows the definition and function of the selected elements.
! (exclamation point) An empty column used to invoke a sort by policy precedence. Clicking the column
header will sort the policies in precedence order.
Name The name of the policy.
Type The type of policy (Access-based security, IP, source physical port, or VLAN).
Enabled Indicates whether the policy is enabled. A green check (
enabled. A red X (
enabled will not be configured on any devices, either automatically or when you start a
configuration manually.
EPICenter Reference Guide
248).
) indicates that the policy is not enabled. A policy that is not
The Policies View
) indicates that the policy is
