Extreme Networks EPICenter Reference Manual page 498

Using the Policy Manager
Figure 261: Edit Policy Scope window
The left side of this window Select Policy Access Domain Devices to be Added, or Select Policy Scope
Devices to be Added displays a component tree showing the resources currently defined in the
Grouping applet.
When you select a group in the component tree, its children (groups or individual devices) are
displayed in the associated Resource list (the right half of the Select Policy Access Domain Devices to
be Added or Select Policy Scope Devices to be Added area). You can select groups or devices as scope
resources. If you select a group that does not contain any devices as children, the group is added as an
access domain resource, but will not actually have any effect on the policy access domain.
The area on the right of the window Current Policy Access Domain Devices, shows the resources you
have already selected to include in the access domain for your policy.
1 Add or remove resources from the Current Policy Access Domain Devices list:
Add
Add All
Remove
Remove All
2 In addition to selecting resources, you can select the QoS Profile that should be configured on the
device for this policy.
a Select a resource in the Current Policy Access Domain Devices list.
498
Select one or more individual resources or groups from the Devices list, and click
the Add button to add them to the Current Access Domain Devices list.
Click the Add All button to add all the resource children of the group you have
selected in the component tree.
To remove selected resources from the Current Domain Devices list, select the
resources and click the Remove button.
To remove all resources from the Current Policy Domain Devices list, click the
Remove All button.
EPICenter Reference Guide
