will be a uniform solid color, click in the checkbox to remove the check mark. The default is to use a
gradient background.
Set the Map Node Font Size to change the size of the font used for map node labels (names,
●
annotations, IP addresses and so on). The default is a 12-point font.
Uncheck the Display device names checkbox to hide device names on the maps. Check the
●
checkbox to show the device names. The default is to display device names.
Uncheck the Display device icons checkbox to use plain boxes to indicate map nodes instead of
●
icons representing specific device types. Check the checkbox to display device icons. The default is
to display device icons.
To select whether RMON statistics should be enabled for this map, click the checkbox labeled Rmon
●
Statistics. When RMON statistics are on for a map, the percent utilization will be displayed for links.
RMON statistics can be enabled separately for each map in the view. The default is to have RMON
statistics disabled for the map.
NOTE
It is possible to disable RMON statistics for the Topology applet as a whole, so that the RMON Statistics
checkbox will not have any effect. This is done setting RMON properties on the Server Properties page of the
Administration applet.
Adding Map Background Images
You can add images of your own to use as background images for topology maps by placing them in
the directory in the EPICenter server installation.
BackgroundImages
Both and image types are supported.
.gif .jpg
Background images are kept in the directory
<EPICenter_install_dir>\extreme\gifs\topology.BackgroundImages
where
<EPICenter_install_dir>
in the Windows operating environment, or
epc4_1

Print Map

You can print the current map using the Print Map function. To print a map, display the map you want
to print and then do one of the following:
Select Print Map from the Map menu.
●
Enter [Ctrl]+P from the keyboard.
●
Printing a large map can be very memory-intensive, and can take a significant amount of time.
NOTE
Landscape mode and plotters are not supported.
EPICenter Reference Guide
is the root directory of your EPICenter server installation (by default
/opt/extreme/epc4_1
The Map Menu
on a Solaris system .
)
