The information presented for each VLAN in the domain includes:
Name The name of the VLAN.
Devices The number of devices participating in this VLAN for this domain.
Ports The number of ports participating in this VLAN in this domain, if the domain is
enabled. This will be zero if the STP domain is disabled on the bridge.
The panel at the bottom of this view shows summary information about the STP domain in which these
VLANs are included.

Displaying STP Device Configurations

Select a specific STP VLAN in the Component Tree to view summary information about the devices in
the selected VLAN that participate in the STP domain. When you select a VLAN, the STP Devices view
appears, as shown in Figure
Figure 277: STP Devices view
This view shows information about the devices participating in the selected VLAN within this domain.
The information presented for each device includes:
Name The name of the device.
State The state of STP on this domain (enabled or disabled). If disabled, most of the
remaining fields are zero.
EPICenter Reference Guide
277.
Displaying STP Domain Information
547
