The ACL Viewer
The rows in the comparison display are displayed in colors that indicate the status of the rule:
White
Yellow
Blue
The columns in the display show information as follows:
! (exclamation point)
Policy
Ideal Rule VLAN
Ideal Rule Profile
Config Rule VLAN
Config Rule Profile

View Policy Rules

The Policy Rules display shows details of the Ideal Source Port QoS rules, as generated by the
EPICenter Policy Manager. The information in this display is as follows:
! (exclamation point)
Policy
VLAN
Profile
To be used

View Configured Rules

The Configured Rules display shows details of the VLAN QoS rules that are actually configured on the
device, either through the EPICenter Policy Manager or the ExtremeWare CLI. The information in this
display is as follows:
VLAN
Profile
518
The rule is valid, and has been configured on the device. Both the Ideal and Configured
sides of the table are filled in.
The EPICenter-generated "ideal" rule conflicts with a rule already configured on the
device. Two rules conflict when the traffic patterns for the rule are the same but the
treatment specified (the QoS profile) is different. Both the Ideal and Configured sides of
the table are filled in.
The rule is configured on the device, but it was not generated by the EPICenter Policy
Manager. Only the Configured side of the table is filled in for these rules.
An empty column used to invoke a sort by policy precedence. Clicking the column
header will sort the policies in policy precedence order.
Displays the name of the policy.
The VLAN specified by this policy.
The QoS profile specified for this traffic flow by this policy.
The VLAN to which the QoS rule applies.
The QoS profile that applies to this VLAN.
An empty column used to invoke a sort by policy precedence. Clicking the column
header will sort the policies in policy precedence order.
Displays the name of the policy.
The VLAN specified by this policy.
The QoS profile that is specified for this VLAN by this policy.
Indicates whether the rule is acceptable for configuration on the device (not in conflict
with any other rules). Values for this column are:
• Yes, the rule can be used.
• No (duplicated) indicating that the rule duplicates another rule.
• No (disabled) indicating that the policy is disabled.
Specifies the VLAN to which the VLAN QoS rule applies.
The QoS profile that applies to this traffic flow.
