Configuration Manager
Figure 78: The Setup Viewers window
To set up a Configuration Viewer:
●
a Uncheck the Use Default Configuration Viewer checkbox
b Type the path and filename of the viewer you want to use, or use the browse button (three dots)
to select a viewer executable file.
To set up a Difference Viewer, type the path and filename of the Difference Viewer, or use the browse
●
button (three dots) to select a viewer executable file.

Configuring the TFTP Server

If you already have a TFTP server installed on the system where the EPICenter server is running, you
may choose to use that TFTP server instead of the one provided with EPICenter. The TFTP server
configured through EPICenter is the one that is used for downloading and uploading from the devices.
NOTE
The Configuration Manager may cause multiple devices to contact the TFTP server at once to perform upload or
download operations. Some third party TFTP servers have problems accepting multiple TFTP requests. If you are
running a third party TFTP server and this happens, disable the TFTP server and use the EPICenter TFTP server.
The Configure TFTP Server function lets you enable or disable the embedded TFTP server, and specify
an alternate path for the location of the server.
Click the TFTP button at the top of the window to display the Configure TFTP Server window, as
shown in Figure
170
79.
