Using the Policy Manager
The fields in this window are as follows:
QoS Profile
Min Bandwidth
Max Bandwidth
Priority
To modify the settings or device scope of a QoS profile, follow these steps:
1 Select the profile you want to modify from the drop-down menu.
The default definitions for the eight QoS profiles you can configure are shown in
Table 57: Default QoS Profile Settings
QoS Treatment Name
QP1
QP2
QP3
QP4
QP5
QP6
QP7
QP8
NOTE
For devices running older versions of ExtremeWare (prior to 6.x) only four QoS profiles (QP1-QP4) are supported.
Their priorities are low, normal, medium, and high. If you select a profile that is not supported on the device you
are configuring, the profile will not be configured on the device.
2 To change the minimum bandwidth for the profile, type a value into the Min Bandwidth field. The
value must be between 0 and 89, and less than or equal to the value you plan to use for maximum
bandwidth.
NOTE
The sum of all minimum bandwidth cannot be greater than 90%.
3 To change the maximum bandwidth for the profile, type a value into the Max Bandwidth field. The
value must be between 0 and 100, and greater than or equal to the minimum bandwidth specified in
the previous field.
4 To change the priority, select one of the eight priorities (low, lowHi, normal, normalHi, medium,
mediumHi, high, highHi, or deny) from the drop-down menu in the Priority field.
5 To specify the devices or ports on which this modified profile should be configured, select devices or
groups from the Select Resources to be Added part of the window, and move them to the Resource
Results list.
504
Select a QoS profile from this drop-down menu.
Use this field to change the minimum bandwidth for the profile, by typing in a value
between 0 and 89, and less than or equal to the value you plan to use for maximum
bandwidth. The sum of all minimum bandwidth cannot be greater than 90%.
Use this field to change the maximum bandwidth for the profile, by typing in a value
between 0 and 100, and greater than or equal to the minimum bandwidth specified in
the previous field.
Select one of the eight priorities (low, lowHi, normal, normalHi, medium, mediumHi,
high, highHi, or deny).
Priority
low
lowHi
normal
normalHi
medium
mediumHi
high
highHi
Min Bandwidth
Max Bandwidth
0
100%
0%
100%
0%
100%
0%
100%
0%
100%
0%
100%
0%
100%
0%
100%
Table
57.
EPICenter Reference Guide
