Results From The Stand Alone Diagnostics Test; The Stand Alone Diagnostic Result Page - Tandberg Data SLR7-140 PROGRAMMER Manual

BYTE BIT 7
00 Page Code
01 RESERVED
02 Page Length
03
04 First failing AID no.
05 Result from the last SAD
06 Tape format
07 RESERVED
08 Time Stamp for last completed SAD
09
10
11
12 Current Time Stamp
13
14
15
Table 21-5:
Page Code
Page Length
First failing AID
no.
Result from the
last SAD
Tape format
Tandberg Data
21.4. Results From the Stand Alone
Diagnostics Test
When the Page Code is set to 98h, the analysis data returned will be from the last
completed Stand Alone Diagnostics test.
The results from the Stand Alone Diagnostic survives
Reset/Power On.
about the Stand Alone Diagnostic test.
21.4.1.

The Stand Alone Diagnostic Result Page

6 5
The Stand Alone Diagnostic Page
This field is always set to 98h.
This field specifies the length in bytes of the analysis
data that follow this field. The Page Length will have a
value of 12.
If the last completed Stand Alone Diagnostics test has
failed, this field will be set to the first failing
Activity Id (AID) number.
If the last Stand Alone Diagnostics test has been
successfully completed, this field will be set to FFh.
This field is set to the test result for the last
completed Stand Alone Diagnostics test. This field can
have the following values:
00h: Stand Alone Diagnostics test successfully
completed.
01h: Stand Alone Diagnostics test has failed.
This field is set to the tape format in the last
completed Stand Alone Diagnostics test.
21-6 Tandberg SLR Product Line SCSI Functional Specifications
See the Reference Manual for details
4 3
Receive Diagnostic Results
2 1 0
