SP
Parameter List
Length
Tandberg Data
A Save Pages (SP) bit of zero indicates that the Drive
will perform the specified MODE SELECT operation, but
not save any mode parameters. A SP bit of one indicates
that the Drive will perform the specified MODE SELECT
operation and save all savable MODE SELECT parameters
including any sent during the DATA-OUT phase
This field specifies the length in bytes of the MODE
SELECT parameter list that will be transferred from the
Initiator to the Drive during the DATA-OUT phase. A
Parameter List Length of zero indicates that no data
will be transferred. No mode selection parameters are
then changed. If the parameter list length results in
truncation of any Header, Descriptor or Page, the Mode
Select command terminate with CHECK CONDITION.
14.3. Parameter List
The MODE SELECT parameter list consists of three sub-
lists. The first list is a 4 byte Header List. This may
be followed by a 8 byte Block Descriptor List. At last
there may be one or more Page Descriptor Lists. The Page
Descriptor Lists may be transferred in any order.
The Drive supports the following Page Descriptor Lists:
01h :
Read-Write Error Recovery Page
02h :
Disconnect/Reconnect Page
0Ah :
Control Mode Page
0Fh :
Data Compression Page
10h :
Device Configuration Page
11h :
Medium Partition Page(1)
1Ch:
Informational Exceptions Control Page
20h :
Miscellaneous Parameter Page
21h :
User Page 0
22h :
User Page 1
23h :
Cartridge Manufacturer Page
: This page is savable
1
The Drive is specified to perform up to a maximum of 100 000 save
operations.
14-2
Tandberg SLR Product Line SCSI Functional Specifications
Mode Select
1
.
