BYTE BIT 7
00 PS
01 Page Length = 0Ah
02 User Defined Field
03 User Defined Field
04 User Defined Field
05 User Defined Field
06 User Defined Field
07 User Defined Field
08 User Defined Field
09 User Defined Field
10 User Defined Field
11 User Defined Field
PS
Page Code
Page Length
User Defined Field
Tandberg Data
14.3.11. User Page 0
This page can be used to save any information (up to ten
bytes).
The page can be saved.
6 5
R Page Code = 21h
Table 14-26: User Page 0 Page Descriptor
The Parameter Savable (PS) bit must be set to zero.
The Page Code for this page must be set to 21h.
The Page Length field must always be set to 0Ah.
These fields can be used to store up to ten bytes of
user defined information.
Any value is legal (no check).
The default (factory programmed) value is 00h.
14-35 Tandberg SLR Product Line SCSI Functional Specifications
4 3 2
Mode Select
1 0
