Tandberg Data SLR7-140 PROGRAMMER Manual page 120

BYTE BIT 7
37 Main Microcode Branch Revision Level
38
39
40
41 Main Microcode ID
42
43 DSP Microcode Revision Level
44
45
46
47 DSP Microcode Release Status
Peripheral Qualifier
Peripheral Device
Type
RMB
ISO/IEC
ECMA
ANSI
AERC
TrmTsk
NormACA
Response Data
Format
Additional Length
EncServ
MultiP
MChngr
ACKQREQQ
Tandberg Data
6 5
Table 9-2: INQUIRY Parameter List
This field will normally be set to zero. However, when
an Unsupported LUN condition exists (if an IDENTIFY
message is received, the LUN field in the Command
descriptor block will be ignored and only the LUN field
in the IDENTIFY message will be evaluated.), this field
will be set to 3.
This field is normally set to 1. When an Unsupported LUN
condition exists , this field will , however, be set to
1Fh.
Removable Medium. This field is always set to 1.
ISO/IEC version is always set to zero (ISO compliance is
not claimed).
ECMA version is always set to zero (ECMA compliance is
not claimed).
The ANSI version is set to 2 (the Drive complies with
ANSI X3.131-1994).
This bit is set to zero (no Asynchronous Event Reporting
Capability).
This bit is set to zero to indicate that the Drive does
not support the TERMINATE TASK message.
The Normal ACA Supported bit is set to zero to indicate
that Drive does not support setting the NACA bit of the
Control Byte to one.
This field is set to 2 (SCSI-2 Standard Format).
This field specifies the number of additional INQUIRY
parameter bytes. This field is always set to 43 (2Bh).
The Enclosure Service bit is set to zero indicate that
the Drive does not contain an embedded enclosure
services component
This bit set to zero, to indicate that this device has a
single port.
This bit is set to zero, to indicate that this device is
NOT attached to a medium transport element.
This bit is set to zero, to indicate that the Drive has
no ACK or REQ signals on a Q cable.
9-4 Tandberg SLR Product Line SCSI Functional Specifications
4 3 2
Inquiry
1 0
