Storage Device Installation

Click on an appropriate procedure for installing a storage device in the system.
T
Installing the 3 1/2-Inch Drive
T
Removing the Side and Front Panels
T
Installing the 5 1/4-Inch
T
Replacing the Front Panel and Side Panel

3 1/2-Inch Drive Installation

Use the following procedure to install a hard disk drive.
Remove the system unit cover (see "System Unit Cover Removal" earlier in this
1.
section).
2. Follow the preinstallation instructions that come with the device, such as setting
jumpers and switches.
3. Remove and label any cables that interfere with installing the device.
4. To install the internal hard disk drive, you must first remove the power supply.
Option Installation 3-23
