Chassis Intrusion Connector
Table A-11 provides the pin asignments for the chassis intrusion connector.
Pin
1
2
STORAGE DEVICE CONNECTORS
The following figure shows the connectors on the system board for the diskette drive and
IDE hard disks. For more information, see the following subsections.
Figure A-5 Storage Device Connector Locations
Table A-11 Chassis Intrusion Pin Assignments
Signal Name
Ground
CHS_SEC
Connector Pin Assignments
A-7
