1-16 Technical Information

Video Support

Matrox Mystique configurations come with 2 MB of video memory on the video board,
upgradeable to 4 MB of video memory using a video upgrade module. Number Nine
Imagine 128 Series 2 configurations come with 4 MB of video memory (not upgradable).
The default video mode is 800 by 600 pixels with 256 colors. To change the default video
resolution, see "Changing Display Properties" in Section 2.
The system supports the following resolutions, colors, and refresh rates for the 2-MB
Matrox Mystique video board installed in some models (see Table 1-8). Screen resolution,
pixel depth, and refresh-rates are with the standard 2 MB of video RAM and with the 2 MB
option installed on the video board.
Table 1-8 Matrox Mystique Video Board Support
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1200
The system supports the following resolutions, color depths, and refresh rates for the
Number Nine Imagine Series 2 video board installed on some PowerMate Professional
Series models (see Table 1-9). Screen resolution, pixel depth, and refresh rates are with the
standard 4 MB of video RAM installed on the video board.
Table 1-9 Number Nine Imagine Video Board Support
Bits/Pixel
(2 MB)
8, 16, 24
8, 16, 24
8, 16
8, 16
8
8
Number of
Resolution Colors
640 x 480 16 M
800 x 600 16 M
1024 x 768 16 M
1152 x 864 16 M
1280 x 1024 65 K
1600 x 1200 65 K
1920 x 1080 65 K
M = millions; K = thousands
Maximum
Bits/Pixel Refresh
(4 MB) Rate
8, 16, 24 200 Hz
8, 16, 24 150 Hz
8, 16, 24 130 Hz
8, 16, 24 120 Hz
8, 16, 24 90 Hz
8, 16 60 Hz
Maximum
Refresh rate
150 Hz
150 Hz
150 Hz
150 Hz
118 Hz
83 Hz
72 Hz
