Power On Connector

The following figure shows the power on connector on the system board. Table A-19
provides the pin assignments.
Pin
1
2

ISA, PCI, AND SIMM CONNECTORS

Figure A-13 shows the location of the ISA, PCI, and SIMM connectors on the system
board. For more information see the following subsections.
Figure A-13 PCI, ISA, and SIMM Connector Locations

ISA Pin Assignments

Table A-20 provides ISA connector pin assignments.
Speaker Reset Pwr LED HDLED Infrared
Figure A-12 Power On Connector
Table A-19 Power On Pin Assignments
Signal Name
SW_ON#
Ground
Connector Pin Assignments
1 2
Sleep Power On
