3-26 Option Installation
6. Secure the device to the bottom of the system.
Connect the drive cables.
7.
Replace the power supply and reattach the power supply cables to the system
8.
board.
Replace the four screws.
9.

Removing the Side Panel

Remove the side panel only if you are installing a 5 1/4-inch device. The side panel does not
need to be removed if you are installing a 3 1/2-inch hard disk drive.
Figure 3-21 Securing a 3 1/2-inch Drive
