A-10
Connector Pin Assignments
LED CONNECTORS
The following figure shows the location of the LED connectors on the system board. For
more information, see the following subsections.
Hard Drive LED Connector
The following figure shows the hard disk LED connector on the system board. Table A-14
provides the pin assignments.
Pin
1
2
3
4
Figure A-6 LED Connectors
1
Speaker
Reset Pwr LED
HDLED Infrared
Figure A-7 Hard Disk LED Connector
Table A-14 Hard Disk LED Pin Assignments
Signal Name
+5V (white)
HD ACTIVE
Key
+5V
4
Sleep Power On
