2-18 Setup and Operation
Processor Type
This field cannot be entered; it is an information field only. The processor is Intel Pentium II
microprocessor that is backward compatible with 8086, 80286, I386, I486, Pentium, and
Pentium Pro processors.
Processor Speed
This field cannot be entered; it is an information field only. The processor operates at an
internal speed of 233 MHz or 266 MHz and an external speed of 66 MHz.
Cache Size
This field cannot be entered; it is an information field only.
Peripheral Configuration
When the cursor is placed in the Peripheral Configuration field, you can select it by pressing
. The Peripheral Submenu appears for setting parameters that affect the IDE devices,
Enter
diskette drive, serial ports, and parallel port.
Peripheral Submenu
The Peripheral Submenu lets you check or change the following peripheral parameters.
Peripheral Configuration Mode
The Peripheral Configuration Mode fields control whether the onboard resources are
manually or automatically set up. The options are as follows.
T
Auto (default)
ports, and parallel port during power up.
T
Manual provides the following options. This selection allows you to customize
the peripheral ports.
PCI IDE Interface (Primary and Secondary)
The Primary and Secondary PCI IDE Interface fields enable the PCI IDE interface
connectors on the system board. These fields can be either "Auto" detected or "Disabled."
The default is "Auto."
CAUTION: Setting items in this menu to
incorrect values can cause the system to
malfunction.
automatically configures the IDE devices, diskette drive, serial
