3-12 Option Installation
1. Locate the four SIMM sockets on the system board (see Figure 3-4).
If any cables block access to the SIMM sockets, label and disconnect them.
Use Table 3-1 to determine the SIMM configuration you need to upgrade
2.
memory and to identify the sockets for SIMM installation.
Table 3-1 Recommended Memory Upgrade Path
Total
Memory
32 MB*
48 MB
80 MB
32 MB
40 MB
48 MB
64 MB
96 MB
64 MB**
72 MB
80 MB
96 MB
128 MB
128 MB
136 MB
144 MB
160 MB
192 MB
256 MB
* Standard configuration for 32-MB systems.
** Standard configuration for 64-MB systems.
SIMM
Socket 1 Socket 2
16 MB 16 MB
8 MB 8 MB
8 MB 8 MB
8 MB 8 MB
16 MB 16 MB
16 MB 16 MB
16 MB 16 MB
16 MB 16 MB
32 MB 32 MB
32 MB 32 MB
32 MB 32 MB
32 MB 32 MB
32 MB 32 MB
64 MB 64 MB
64 MB 64 MB
64 MB 64 MB
64 MB 64 MB
64 MB 64 MB
64 MB 64 MB
SIMM
Socket 3 Socket 4
Empty Empty
16 MB 16 MB
32 MB 32 MB
8 MB 8 MB
4 MB 4 MB
8 MB 8 MB
16 MB 16 MB
32 MB 32 MB
Empty Empty
4 MB 4 MB
8 MB 8 MB
16 MB 16 MB
32 MB 32 MB
Empty Empty
4 MB 4 MB
8 MB 8 MB
16 MB 16 MB
32 MB 32 MB
64 MB 64 MB
