SIMM Removal

If the SIMM configuration requires the removal of a SIMM, remove the SIMM as follows.
Remove the system unit cover.
1.
Locate the SIMMs sockets on the system board (see Figure 3-8).
2.
3. Press the metal clips at the outer edges of the socket away from the SIMM (see
Figure 3-8).
4. Push the SIMM away from the locking tabs and remove it from the socket.

SIMM Installation

Remove the system unit cover (see "Removing the System Unit Cover").
1.
Locate the correct SIMM sockets for the desired configuration (see Figure 3-4
2.
and Table 3-1).
If you need to remove a currently installed SIMM, see "SIMM Removal."
CAUTION: Reduce static discharge by touching
the system's metal chassis.
Figure 3-8 Removing a SIMM
CAUTION: Before you install a SIMM, reduce
static discharge by touching the system's metal
chassis.
Option Installation 3-13
