5-6 Repair
2. Locate the SIMMs sockets on the system board (see Figure 5-5).
Press the metal clips at the outer edges of the socket away from the SIMM (see
3.
Figure 5-6).
Push the SIMM away from the locking tabs and remove it from the socket.
4.
Repeat steps 3 and 4 for each SIMM being removed.
Figure 5-5 System Board SIMM Sockets
NOTE: For information on installing SIMM
sticks, see Section 3, "Options."
Figure 5-6 Removing a SIMM
