Desktop Storage Device Installation

Installing a Desktop Storage Device

6-44 Adding Options
In multimedia configurations the CD-ROM is connected to
the secondary PCI/IDE connector on the system board. If
installing two devices to the secondary PCI/IDE connector,
the IDE interface cable shown in the following figure is
required.
CAUTION: The IDE device cables are
not keyed to fit only in the correct position. Align the
red edge of the cable with pin 1 of the connectors on
the drive and system board.
The following section is used to install a 5 1/4-inch device
or 3 1/2-inch hard disk drive in your desktop system. If in-
stalling a device into the minitower system see "Minitower
Storage Device Installation" later in this chapter.
Install a storage device in the system as follows.
Follow the preinstallation instructions that come with
1.
your device, such as setting jumpers and switches.
Optional PCI/IDE cable
