Pull the cover up and free it from the chassis.
5.
To replace the system unit cover, see "Replacing the System Unit Cover."

Replacing the System Unit Cover

Position the cover on the side of the system unit about one inch back from the
1.
front panel. Turn off and unplug the system unit.
2. Insert the metal tabs on the top of the system unit cover into their slots on the
chassis.
3. Insert the metal tabs on the bottom of the cover into the slots on the chassis (see
Figure 3-3).
Figure 3-2 Releasing the System Unit Cover
CAUTION: To prevent damage to system
cables, carefully tuck the cables out of the path
of the cover.
Option Installation 3-5
