ILLUSTRATED PARTS BREAKDOWN

This subsection contains the illustrated parts breakdown (IPB) and NECCSD part numbers
for the PowerMate Professional Series computers.
The information in this subsection applies to the following model numbers:
T
MT-2550-24874X
T
MT-2560-24874X
T
MT-2560-24874C
T
MT-2560-2784S
T
MT-2560-2785S.
Table 5-2 lists the field-replaceable parts for the computer. Figure 5-18 provides the
illustrated parts breakdown.
Use the following telephone numbers when ordering parts.
T
Dealers in the U.S. should call 1(800) 632-4565 to order NECCSD spare parts.
T
Users in the U.S. must call 1(800) 632-4565 for parts.
T
Users in Canada must call 1(800) 727-2787 for parts.
T
To order options in the U.S., call the NECCSD sales office at
1-888-306-4636.
Table 5-2 PowerMate Professional Series Field-Replaceable
Item
1
2
2a
3
4
5
6
7
8
____________
*This data was prepared May 1997. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476 and
order document number 42181764.
Parts List*
Description
AC Power Cable
Chassis Intrusion Switch and
Cable Assembly
Plastic Chassis Intrusion Switch
Housing
LED Power Cable
HDD LED Cable
Sleep Switch Cable Assembly
Reset Switch Cable Assembly
Audio Cable
Microsoft Mouse
Repair
Part Number
808-857649-101A
158-052263-000
158-052262-000
158-052170-001
158-052169-001
158-050895-004
158-050685-031
158-050824-000
158-052115-000
5-17
