SIMM Removal
Remove a SIMM as follows.
Remove the system unit cover as previously described.
1.
Locate the SIMM sockets (see Figure 3-8).
2.
3.
Press the metal clips at the outer edges of the socket away from the SIMM.
4.
Push the SIMM away from the locking tabs and remove it from the socket (see
Figure 3-9).
5.
Install a SIMM per the following procedure.
SIMM Installation
Install a SIMM as follows.
1.
Remove the system unit cover as previously described.
Locate the SIMM sockets (see Figure 3-8).
2.
Remove any currently installed SIMMs that are not needed.
CAUTION: Reduce static discharge by touching
the system's metal chassis.
Clips
Figure 3-9 Removing a SIMM
Option Installation
3-11
