SIMM Removal

Remove a SIMM as follows.
Remove the system unit cover as previously described.
1.
2. Locate the SIMM sockets (see Figure Section 3-14).
3. Press the metal clips at the outer edges of the socket away from the SIMM.
Push the SIMM away from the locking tabs and remove it from the socket (see
4.
Figure Section 3-15).
Install a SIMM per the following procedure.
5.

SIMM Installation

Install a SIMM as follows.
1. Remove the system unit cover as previously described.
2. Locate the SIMM sockets (see Figure Section 3-14).
Remove any currently installed SIMMs that are not needed.
CAUTION: Reduce static discharge by
touching the system's metal chassis.
Clips
Figure Section 3-15 Removing a SIMM
Option Installation 3-11
