7.2.6

OPERATING MODES OF THE CONTROL PANEL

OPERATING MODES OF THE CONTROL PANEL
OFF
AUTO
LOW
EKON
COMFORT
HMI BASIC
www.vtsgroup.com
Air handling unit switched off - fans stopped, air dampers and control
valves closed all sensors and measuring devices remain active - to protect
the unit from damage, e.g. fire alarm, anti-FROST protection.
Panel operation dependent on calendar programming
Lower economy mode - Fan speed as well as the dead zone in temperature
control are adjustable. The temperature control algorithm can use a wide
dead zone, while the fans can be set to low speed to reduce energy
consumption.
higher economy mode - The fan speed as well as the insensitive zone in
the temperature control are adjustable. The temperature control algorithm
can use a narrower insensitive zone, while the fans can be set to a higher
speed to optimise energy consumption.
Factory setting of selection parameters. The settings can be modified by
the user.
Basic mode - external control signals (binary inputs) of critical
temperatures, e.g. too low a temperature, trigger the control unit and
immediately heat the room.
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024) 81
