OTHER DESIGNATIONS IN THE CONTROL PANEL
AD
FLX.CON
IN
OUT
VENTUS COMPACT units have inspection panels located at the front of the unit.
BASE SECTIONS WITH HEAT RECOVERY (ROTARY HEAT EXCHANGER)
The units can be manufactured as right- or left-sided. The orientation of the unit is determined by the
direction of airflow in the supply path (air outlet) in relation to the side of the unit where the inspection
panels are located.
www.vtsgroup.com
Air damper
Flexible duct connection
Inlet (supply of e.g. medium)
Outlet (return e.g. medium)
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
7
