! AHUs without heat recovery require an external power and control switchgear and Control
components to be installed, connected and configured on site.
! See instructions:
•
"Control gear for Supply and Supply-Exhaust Air Handling Units." / "Control gear for Supply
and Supply-Exhaust Air Handling Units."
CONNECTING THE POWER SUPPLY TO THE HEAT RECOVERY CENTRE ( 3~400V AC
50Hz )
Fan code
[-]
225|0.74kW|1.33x2
225|0.74kW|1.33x3
225|0.74kW|1.33x4
250|0.7kW|1.58x1
250|0.7kW|1.58x3
250|0.7kW|1.58x4
250|0.7kW|1.58x5
250|0.7kW|1.58x6
250|0.7kW|1.58x6
250|0.7kW|1.58x7
250|0.7kW|1.58x8
250|0.7kW|1.58x9
250|0.7kW|1.58x10
The units are equipped with modern and efficient fans with EC motors. The IP degree of protection of
the motors with the controller is 44. The motors' own electronics protect them from overloading and
failure.
www.vtsgroup.com
Size
head office
[-]
VVS021c,VVS030c,VVS055c
VVS030c,VVS040c,VVS055c
VVS055c
VVS021c
VVS075c,VVS100c
VVS075c,VVS100c,VVS120c
VVS075c,VVS100c,VVS120c
VVS100c
VVS120c,VVS150c
VVS120c,VVS150c
VVS150c
VVS150c
VVS150c
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
Rated
Power cable
current
[A] [3 400V AC+N+P]
19 5x2.5 mm
22 5x4 mm
26 5x6 mm
19 5x2.5 mm
22 5x4 mm
26 5x6 mm
30 5x6 mm
34 5x6 mm
34 5x10 mm
38 5x10 mm
41 5x10 mm
45 5x10 mm
49 5x10 mm
