The units can be manufactured as right- or left-sided. The orientation of the unit is determined by the
direction of airflow in the supply (bottom) path relative to the side of the unit where the inspection panels
are located.
MARKING OF THE AIR INLET AND OUTLET OF THE AIR HANDLING UNIT
INSPECTION SIDE VIEW - RIGHT-HAND VERSION
EA
Exhaust air outlet
FA
Fresh air intake
MARKING OF THE AIR INLET AND OUTLET OF THE AIR HANDLING UNIT
INSPECTION SIDE VIEW - LEFT-HAND DESIGN
RA
Exhaust air inlet.
SA
Room supply air
outlet
www.vtsgroup.com
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
RA
Exhaust air inlet.
SA
Room supply air
outlet
EA
Exhaust air outlet
.
FA
Fresh air intake
8
