7.2 INITIAL START-UP

7.2.1

FACTORY PARAMETERS

!
! The control unit, which is supplied as a Plug&Play standard, has its Control configured according
to the parameters and criteria specified in the unit's selection sheet.
! No additional site configurations are required in order to run the control unit in Plug&Play in factory
parameter mode (see "Preparing for initial start-up").
! VTS automatics has a wide range of parameters for adjusting the device's operation to the
specifics of the facility's installation. In order to improve the comfort of use, it is recommended
that such adjustment be carried out.
! For basic commissioning of the control panel, it is sufficient:
•
connect peripheral functions and peripheral Control elements depending on the
depending on the retrofit options provided,
•
connect the fan sections (connectors located on the fan diaphragm for pressure
measurement, control signal and power supply of the units),
•
connect the pneumatic differential pressure measurement lines of the air filters,
•
check the correctness of the connections made on the site,
•
check the correctness of the sensor readings and the functioning of the elements mounted
on the site.
!
BASIC FACTORY CONFIGURATION
Configuration of the
application code including:
•
type and mode of heat
recovery operation,
•
the type and parameters of the
main heater,
•
the type and parameters of the
pre-heater,
•
the type and parameters of the
secondary heater,
•
the type and parameters of the
reversible system,
•
mixing chamber parameters,
•
humidifier operating
parameters (air humidity
control),
•
occurrence of HMI Basic, HMI
Basic2,
www.vtsgroup.com
Configuration and settings:
•
leading sensor,
•
type of temperature
control,
•
type of humidity control,
•
type of supply fan control
(CAV/ VAV),
•
type of extractor fan
control (CAV/ VAV),
•
type of supply fan motor
controller (EC),
•
type of extractor fan motor
controller (EC),
•
PID controllers for fans
and other functions in the
application,
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
•
number of supply fans
•
number of exhaust fans
•
supply impeller size,
•
Exhaust impeller size,
•
discharge capacity,
•
exhaust performance,
•
discharge pressure,
•
the discharge pressure,
•
maximum speed for the supply
fan motor,
maximum speed for the exhaust
fan motor,
•
activation of the water heater
touch sensor,
•
Activation of the humidity
transmitter
•
Activation of the CO2 transducer
(VOC sensor),
