3

CONNECTION OF WATER EXCHANGERS

3.1 CONNECTION OF WATER HEATERS AND COOLERS

!
!
The operation of the water exchanger requires its connection to the process heat system
depending on the designed function of this exchanger.
!
Exchangers must be protected against freezing (if there is a risk of this).
!
The connection of additional heat exchangers must be carried out in such a way that no stresses
are caused which could result in mechanical damage or leaks. The weight of the pipes and
thermal stresses must not be transferred to the exchanger connections.
!
Supply lines should be routed to avoid collision with other sections of the air handling unit and
other installations.
!
It must be possible to easily disconnect the heat exchangers from the process heat installation
for maintenance and servicing.
!
Compensation should be used at the inlet and outlet of the joints to compensate for linear
expansion of the pipes.
!
Hydraulic lines must not be routed over electrical lines.
www.vtsgroup.com
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
19
