Sc02
Sc03
Sc04
Sc05
Sc06
Sc07
Sc08
www.vtsgroup.com OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
•
"Recovery supply air" - current supply
air temperature on recovery
•
"Flush" - Current temperature of the
touchdown sensor
secondary heater
•
"Pre-heater" - Current temperature after
the pre-heater
•
"Room TH" - current temperature of the
room sensor
•
"Room" - current humidity in the room
•
"Supply air" - current supply air humidity
value
•
"Exhaust" - current exhaust humidity
value
•
"Pressure - Supply air" - current supply
air pressure
•
"Pressure - Exhaust" - current exhaust
pressure
•
"Airflow - Supply" - current supply
airflow
•
"Airflow - Extract" - current extract
airflow
•
"Exhaust CO2 value" - current exhaust
CO2 level
•
"Fire" - digital fire alarm input status
•
"Remote switch-on" - status of the
digital input responsible for remote
switch-on of the AHU
•
"Supply air filter" - digital input status of
the supply air filter pressure switch
•
"Exhaust filter" - digital input status of
the exhaust filter pressure switch
•
"Heater alarm" - status of the digital
input of the heater alarm
•
"Cooling alarm" - status of the digital
cooler alarm input
•
"Humidifier alarm" - status of the digital
humidifier alarm input
•
"Winter / Summer" - status of digital
input forcing summer / winter operation
mode
•
"Throttles" - digital output status of
dampers
•
"Alarm" - status of the digital output of
the global alarm
•
"Heating" - status of the digital output of
the main heater
of the water
