Dimensions (H x W x
D)
Permissible operating
temperature
Destination
Assembly
Mass
!
!
In the absence of communication with the controller, the HMI Basic 2 HY will only display the
current room temperature.
!
Activation of the panel in the settings of the air handling unit controller The panel is intended for
air handling units equipped with the uPC3 controller with software version 1.0.019 or higher. In
order to activate its operation, it is necessary to go from the HMI Advanced (physical, connected
to the controller's pLAN port, or virtual, being part of the visualisation application) to the service
menu and, on the I01 screen, change the last digit of the application code to 7.
!
The default Modbus address of the HMI Basic 2 HY is 16. It can be changed on the I05 HMI
Advanced screen (HMI Basic 2 line).
!
If there is no communication between the AHU controller and the HMI Basic 2 HY, only the room
temperature will be displayed on the HMI screen and the controller will report the corresponding
alarm (A1096).
!
If there is no communication between the AHU controller and the HMI Basic 2 HY, only the room
temperature will be displayed on the HMI screen and the controller will report the corresponding
alarm (A1096).
www.vtsgroup.com
86 x 86 x 17 mm
for indoor mounting (IP20)
in a standard Ø60 installation box on a mounting bracket
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
0⁰C ... 50⁰C
150g
69
