OVERVIEW OF SELECTED ASPECTS OF THE mHMI APPLICATION
•
The app includes a tutorial for pairing and connecting the device.
PANEL OVERVIEW
www.vtsgroup.com
The PBX View contains the basic operating parameters of the PBX
:
•
outside air temperature,
•
indoor air temperature,
•
the set air temperature (of the lead sensor),
•
degree of fan speed control,
•
state of the panel,
•
selected operation mode of the air handling unit: (eco, opti,
comfort, auto, off)
Changing the target temperature
By clicking on the Thermometer icon, the user is able to
continuously adjust the temperature within limits depending on the
mode.
Changing the operating mode of the control panel
By clicking on the Modes icon, it is possible to change the current
mode, as well as to change the settings for a particular mode.
Revision of the Work Schedule
After clicking on the Scheduler icon, it is possible to change the
time settings with the assignment of modes to the harmongram.
Changing fan speeds
In the bar at the bottom of the screen, it is possible to change the
fan speed settings (within the settings specific to the operating
mode). This can be done by clicking on + or - .
