2.2.4

REQUIREMENTS FOR EQUIPMENT TO BE INSTALLED ON THE SITE

BASIC CONDITIONS FOR ASSEMBLY ON SITE - DELIVERY IN SECTIONS
Section connection is outside the standard VTS offer. It is possible to purchase an additional
1
option of section connection by an Authorised VTS Service.
Assembly may take place at ambient temperatures which allow all technical assembly
2
procedures to be carried out correctly, i.e. in the temperature range: from (+5) C to (+35) C.
In the case of outdoor installation, the installation process can be carried out in conditions that
3
ensure the absence of precipitation.
It is permissible to start installation provided that all safety requirements are met.
Installation is carried out on site. Preparation of the unit's foundation site (frame, foundation,
4
etc. is on the customer's side). Attention must be paid to the requirement described in this
manual.
The following are required for the installation site:
•
access to power supply 1 230V,
•
adequate lighting of the installation site,
•
providing a safe environment for the installation team,
•
availability of individual panel components or pallets including packaging at the site of
5
the specific panel,
•
ensures that AHU components and AHU blocks are transported to the installation site,
•
the possibility for the service to enter the site and begin installation immediately upon
arrival,
•
provision of the warranty card and delivery documents for the specific PBX for the
installation service.
When installing on your own, follow the separate instructions provided with the AHU in the
6
installation kit. The instructions are available on the manufacturer's website.
When connecting the section, care must be taken to ensure that the "D" gasket, which is part
of the section assembly kit, is correctly applied (a connection made without using the enclosed
7
gasket will result in the housing not being airtight - warranty claims for this reason will not be
considered).
