SUPPLY PRINCIPLE FOR WATER EXCHANGERS
a) Left-hand execution
b) Right-hand execution
(1) Heating/cooling medium supply to the exchanger
(2) Return from the factor exchanger
(3) Direction of air flow in the air handling unit
PRINCIPLE OF CONNECTING VALVES TO WATER EXCHANGERS
www.vtsgroup.com
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
`
!
The exchanger's fluid supply and
return connections should be
configured so that the exchanger
operates
in
countercurrent
mode. The co-current mode of
operation
of
the
provides
a
lower
temperature difference, affecting
its operating efficiency.
!
exchanger
average
21
