VTS Medical Systems VENTUS COMPACT VVS021c Instructions For Use Manual page 119

I41
I42
I43
I44
I45
www.vtsgroup.com OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
•
"Password" - use of password to
change / save parameters
•
"Reading" - reading
programmed parameters
•
"Modbus address
motors" - address of individual supply
fan motors on Modbus
•
"Modbus address of exhaust fan
motors" - address of individual exhaust
motors on Modbus
•
"Maximum speed of the supply fans" -
the maximum speed of the individual
supply EC motors set in their controllers,
which is the reference for adjustment by
the AHU controller
•
"Maximum speed of the exhaust fans"
- maximum speed of the individual
exhaust EC motors
controllers, which is the reference for the
control by the AHU controller
•
"Maximum speed of the supply fans" -
the maximum speed of the individual
supply EC motors set in their controllers,
which is the reference for adjustment by
the AHU controller
•
"Maximum speed of the exhaust fans"
- maximum speed of the individual
exhaust EC motors
controllers, which is the reference for the
control by the AHU controller
•
"Maximum RPM from technical card -
supply" - maximum speed of the supply
EC motors, as read from their technical
card
•
"Maximum RPM from technical card -
exhaust" - maximum speed of the
exhaust EC motors, as read from their
technical card
•
"Supply fan" - coefficient for supply EC
motors, allowing their speed to be
increased above the maximum speed set
during the AHU installation process
(standard = speed set during the
installation process, set = standard
including the set coefficient, maximum =
maximum permissible
resulting from its type)
•
"Exhaust fan" - coefficient for exhaust
EC motors, allowing their speed to be
increased above the set maximum speed
•
"Air supply EC motor alarm delay" -
delay of activation of selected alarms
(lack of communication, IGBT, overload)
for given air supply EC motors in relation
to the time of their cause
•
"Exhaust EC motor alarm delay" -
delay of activation of selected alarms for
out newly
of supply fan
set in their
set in their
motor speed
