Equipment packaging:
should be placed in paved, dry locations protected from precipitation,
should be placed and stored away from areas with active mechanical equipment (vehicles,
cranes and other construction machinery),
should be stored in places where they will not be exposed to any mechanical damage:
moisture, aggressive chemicals, liquids, dust and any other external factors whose influence
may impair their technical and functional condition.
VTS recommends leaving the units and their equipment in their transport packaging on pallets for
protection and to facilitate proper positioning during installation.
!
!
The equipment as well as its components should be:
stored in rooms with the following conditions:
o
o
protected
from
as well as with any other chemical substances liable to have a corrosive effect on the
equipment or its accessories.

2.2 PREPARATION FOR INSTALLATION

Transport of the equipment requires lifting equipment at the installation site. Make sure that once the
unit is installed, there will be enough space to properly bring the technological and electrical installations
to the unit and to carry out maintenance on the unit without any problems.
2.2.1

LOCATION OF THE DEVICE

Allow adequate space for the placement of piping and electrical connections. All piping and ducting
should be fixed independently of the air handling unit to reduce excessive noise and vibration.
RECOMMENDATIONS FOR THE LOCATION OF THE DEVICE
The weight of the appliance must be taken into account. When doing so, refer to the weight of
1
the appliance on its rating plate. The weight on the rating plate does not take into account the
weight of the media, which should be taken into account when installing the appliance.
Sufficient space should be left to allow for the removal of enclosure panels and for access to
2
carry out maintenance work.
3
The installer must provide a lifting device to lift the panel or heavier panel components.
4
All equipment must be mounted horizontally.
Consideration should be given to the requirements for coil and drain pipework and condensate
5
drainage.
www.vtsgroup.com
relative humidity: φ < 80 %, at t = (+20) °C,
ambient temperature: (-40) °C < t < (+60) °C.
contact
with
corrosive
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
(caustic)
dusts,
gases
or
vapours,
12
