CONNECTING THE CHANNEL MODULE
CONNECTING THE FAN SECTION
"+" higher pressure side (red wire), "-" lower pressure side (blue wire),
www.vtsgroup.com
OIMM VENTUS COMPACT - ver. 6.0.0 (06.2024)
The VENTUS COMPACT base
configuration with heat recovery
is supplied as a wired unit with
the Control system connected
and
configured.
Using the supplied connectors
(electrical
cable,
pneumatic
cable), connect the fan and air
filtration sections to the base
section (with heat pump).
