6 PLUG&PLAY CONTROL COMPONENTS
The VENTUS COMPACT base unit with heat recovery (counter-flow hexagonal exchanger or
rotary exchanger), fans and air filters is supplied as a pre-wired unit with the configured Control
system connected. The Control system is based on the factory-programmed and built-in uPC3
controller.
Peripheral Control components whose specifics require installation outside the base unit (room
or duct mounted sensors, actuators, valves) are supplied in separate packages. It is necessary
to connect them on site according to the installation and connection instructions.
LABELLING OF PLUG&PLAY CONTROL COMPONENTS
Control components requiring connection
on site are equipped with connection cables
that include a label with the method of
connection to Terminal 1.
