NetApp ASA C Series Install page 87

1. Locate and replace the impaired NVMEM battery on your controller module.
It is recommended that you follow the illustrated instructions in the order listed.
2. Locate the battery plug and squeeze the clip on the face of the battery plug to release the plug from
the socket.
3. Grasp the battery and press the blue locking tab marked PUSH, and then lift the battery out of the
holder and controller module and set it aside.
4. Remove the replacement NV battery from the antistatic shipping bag and align it to the battery holder.
5. Insert the replacement NV battery plug into the socket.
6. Slide the battery pack down along the sheet metal side wall until the support tabs on the side wall
hook into the slots on the battery pack, and the battery pack latch engages and clicks into the opening
Squeeze the clip on the face of the battery plug.
Unplug the battery cable from the socket.
Grasp the battery and press the blue locking tab
marked PUSH.
Lift the battery out of the holder and controller
module.
85
