Carefully hold the DIMM by the edges to avoid pressure on the components on the
DIMM circuit board.
4. Remove the replacement DIMM from the antistatic shipping bag, hold the DIMM by the corners, and
align it to the slot.
The notch among the pins on the DIMM should line up with the tab in the socket.
5. Insert the DIMM squarely into the slot.
The DIMM fits tightly in the slot, but should go in easily. If not, realign the DIMM with the slot and
reinsert it.
Visually inspect the DIMM to verify that it is evenly aligned and fully inserted into the
slot.
6. Push carefully, but firmly, on the top edge of the DIMM until the ejector tabs snap into place over the
notches at the ends of the DIMM.
7. Reinstall any risers that you removed from the controller module.
8. Close the air duct.
== Step 4: Reinstall the controller module and booting the system
After you replace a FRU in the controller module, you must reinstall the controller module and reboot it.
1. If you have not already done so, close the air duct:
a. Swing the air duct all the way down to the controller module.
b. Slide the air duct toward the risers until the locking tabs click into place.
c. Inspect the air duct to make sure that it is properly seated and locked into place.
