until it locks into place.
7. Plug the battery plug back into the controller module, and then close the air duct.
== Step 4: Install the controller module
After you have replaced the component in the controller module, you must reinstall the controller module
into the chassis, and then boot it.
You can use the following animation, illustration, or the written steps to install the controller module in the
chassis.
Animation - Install the controller module
Controller module
Controller locking latches
1. If you have not already done so, close the air duct.
2. Align the end of the controller module with the opening in the chassis, and then gently push the
controller module halfway into the system.
Do not completely insert the controller module in the chassis until instructed to do so.
3. Cable the management and console ports only, so that you can access the system to perform the
tasks in the following sections.
You will connect the rest of the cables to the controller module later in this procedure.
4. Complete the installation of the controller module:
a. Plug the power cord into the power supply, reinstall the power cable locking collar, and then
