- Page 1 Boot media Install and maintain NetApp October 20, 2023 This PDF was generated from https://docs.netapp.com/us-en/ontap-systems/asa-c400/bootmedia- replace-overview.html on October 20, 2023. Always check docs.netapp.com for the latest.
-
Page 2: Table Of Contents
Return the failed part to NetApp - ASA C400 .......... -
Page 3: Boot Media
◦ If the impaired controller is in a standalone configuration and at LOADER prompt, contact mysupport.netapp.com. 2. If AutoSupport is enabled, suppress automatic case creation by invoking an AutoSupport message: system node autosupport invoke -node * -type all -message... - Page 4 Check NVE or NSE on systems running ONTAP 9.6 and later Before shutting down the impaired controller, you need to verify whether the system has either NetApp Volume Encryption (NVE) or NetApp Storage Encryption (NSE) enabled. If so, you need to verify the configuration.
- Page 5 Enter the onboard security key-manager sync command: security key-manager onboard sync Enter the customer’s 32 character, alphanumeric onboard key management passphrase at the prompt. If the passphrase cannot be provided, contact NetApp Support. mysupport.netapp.com b. Verify the column shows...
- Page 6 Enter the onboard security key-manager sync command: security key-manager onboard sync Enter the customer’s 32 character, alphanumeric onboard key management passphrase at the prompt. If the passphrase cannot be provided, contact NetApp Support. mysupport.netapp.com b. Verify the column shows...
-
Page 7: Shut Down The Impaired Controller - Asa C400
d. Go to advanced privilege mode and enter when prompted to continue: set -priv advanced e. Enter the command to display the key management backup information: security key-manager onboard show-backup f. Copy the contents of the backup information to a separate file or your log file. You’ll need it in disaster scenarios where you might need to manually recover OKM. - Page 8 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Return a FIPS drive or SED to unprotected mode" section of NetApp Encryption overview with the CLI.
- Page 9 If the impaired controller… Then… Has automatically switched over Proceed to the next step. Has not automatically switched Perform a planned switchover operation from the healthy controller: over metrocluster switchover Has not automatically switched Review the veto messages and, if possible, resolve the issue and try over, you attempted switchover again.
-
Page 10: Replace The Boot Media - Asa C400
mcc1A::> metrocluster heal -phase root-aggregates [Job 137] Job succeeded: Heal Root Aggregates is successful If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation. - Page 11 NetApp Support Site. You must log into the NetApp Support Site to display the Statement of Volatility for your system. You can use the following animation, illustration, or the written steps to replace the boot media.
- Page 12 Locking tabs Slide air duct toward back of controller Rotate air duct up a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
- Page 13 • A copy of the same image version of ONTAP as what the impaired controller was running. You can download the appropriate image from the Downloads section on the NetApp Support Site ◦ If NVE is enabled, download the image with NetApp Volume Encryption, as indicated in the download button.
- Page 14 Steps 1. Download and copy the appropriate service image from the NetApp Support Site to the USB flash drive. a. Download the service image to your work space on your laptop. b. Unzip the service image.
-
Page 15: Boot The Recovery Image - Asa C400
c. Rotate the locking latches upward, tilting them so that they clear the locking pins, and then lower them into the locked position. d. If you have not already done so, reinstall the cable management device. 8. Interrupt the boot process by pressing Ctrl-C to stop at the LOADER prompt. If you miss this message, press Ctrl-C, select the option to boot to Maintenance mode, and then halt controller to boot to LOADER. - Page 16 If your system has… Then… A network connection a. Press when prompted to restore the backup configuration. b. Set the healthy controller to advanced privilege level: -privilege advanced c. Run the restore backup command: system node restore- backup -node local -target-address impaired_node_IP_address d.
-
Page 17: Switch Back Aggregates In A Two-Node Metrocluster Configuration - Asa C400
8. Give back the controller using the storage failover giveback -fromnode local command. 9. At the cluster prompt, check the logical interfaces with the command. net int -is-home false If any interfaces are listed as "false", revert those interfaces back to their home port using the net int command. - Page 18 (SVMs) on the formerly impaired site now active and serving data from the local disk pools. This task only applies to two-node MetroCluster configurations. Steps 1. Verify that all nodes are in the state: enabled metrocluster node show cluster_B::> metrocluster node show Configuration Group Cluster Node State...
-
Page 19: Restore Okm, Nse, And Nve As Needed - Asa C400
Restore OKM, NSE, and NVE as needed - ASA C400 Once environment variables are checked, you must complete steps specific to systems that have Onboard Key Manager (OKM), NetApp Storage Encryption (NSE) or NetApp Volume Encryption (NVE) enabled. 1. Determine which section you should use to restore your OKM, NSE, or NVE configurations: If NSE or NVE are enabled along with Onboard Key Manager you must restore settings you captured at the beginning of this procedure. - Page 20 6. When prompted to enter the backup data, paste the backup data you captured at the beginning of this procedure, when asked. Paste the output of security key-manager backup show security command key-manager onboard show-backup The data is output from either security key-manager backup show security command.
- Page 21 12. Move the console cable to the target controller. a. If you are running ONTAP 9.6 or later, run the security key-manager onboard sync: b. Run the command and then enter the passphrase when security key-manager onboard sync prompted. c. Enter the command to see a detailed view of all keys stored security key-manager key query in the onboard key manager and verify that the...
- Page 22 4. Move the console cable to the partner controller and give back the target controller storage using the storage failover giveback -fromnode local -only-cfo-aggregates true local command. ◦ If the command fails because of a failed disk, physically disengage the failed disk, but leave the disk in the slot until a replacement is received.
-
Page 23: Return The Failed Part To Netapp - Asa C400
Return the failed part to NetApp - ASA C400 Return the failed part to NetApp, as described in the RMA instructions shipped with the kit. See the Part Return & Replacements page for further information. - Page 24 NetApp. The use or purchase of this product does not convey a license under any patent rights, trademark rights, or any other intellectual property rights of NetApp.
