you must perform a specific sequence of steps.
You can use the following animation, illustration, or the written steps to move the NVDIMM battery from
the impaired controller module to the replacement controller module.
Animation - Move the NVDIMM battery
NVDIMM battery plug
NVDIMM battery locking tab
NVDIMM battery
1. Open the air duct:
a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module.
b. Slide the air duct toward the back of the controller module, and then rotate it upward to its
completely open position.
2. Locate the NVDIMM battery in the controller module.
3. Locate the battery plug and squeeze the clip on the face of the battery plug to release the plug from
the socket, and then unplug the battery cable from the socket.
4. Grasp the battery and press the blue locking tab marked PUSH, and then lift the battery out of the
holder and controller module.
5. Move the battery to the replacement controller module.
6. Align the battery module with the opening for the battery, and then gently push the battery into slot
until it locks into place.
Do not plug the battery cable back into the motherboard until instructed to do so.
== Step 4: Move the boot media
You must locate the boot media, and then follow the directions to remove it from the impaired controller
