1. Align the end of the controller module with the opening in the chassis, and then gently push the
controller module halfway into the system.
Do not completely insert the controller module in the chassis until instructed to do so.
2. Recable the console to the controller module, and then reconnect the management port.
3. Complete the installation of the controller module:
a. Plug the power cord into the power supply, reinstall the power cable locking collar, and then
connect the power supply to the power source.
b. Using the locking latches, firmly push the controller module into the chassis until the locking
latches begin to rise.
Do not use excessive force when sliding the controller module into the chassis to
avoid damaging the connectors.
c. Fully seat the controller module in the chassis by rotating the locking latches upward, tilting them
so that they clear the locking pins, gently push the controller all the way in, and then lower the
locking latches into the locked position.
The controller module begins to boot as soon as it is fully seated in the chassis. Be prepared to
interrupt the boot process.
d. If you have not already done so, reinstall the cable management device.
e. Interrupt the normal boot process and boot to LOADER by pressing Ctrl-C.
If your system stops at the boot menu, select the option to boot to LOADER.
f. At the LOADER prompt, enter
g. Interrupt the boot process and boot to the LOADER prompt by pressing Ctrl-C.
If your system stops at the boot menu, select the option to boot to LOADER.
4. Repeat the preceding steps to install the second controller into the new chassis.
= Complete the restoration and replacement process - ASA C400
:icons: font
:relative_path: ./asa-c-400/
:imagesdir: /tmp/d20231020-12297-25s5m0/source/./asa-c-250/../media/
You must verify the HA state of the chassis and return the failed part to NetApp, as
described in the RMA instructions shipped with the kit.
== Step 1: Verify and set the HA state of the chassis
You must verify the HA state of the chassis, and, if necessary, update the state to match your system
configuration.
1. In Maintenance mode, from either controller module, display the HA state of the local controller
module and chassis:
136
to reinitialize the PCIe cards and other components.
bye
ha-config show
