a. Unplug any cabling associated with the impaired mezzanine card.
Make sure that you label the cables so that you know where they came from.
b. Remove any SFP or QSFP modules that might be in the impaired mezzanine card and set it
aside.
c. Using the #1 magnetic screwdriver, remove the screws from the face of the controller module and
set them aside safely on the magnet.
d. Using the #1 magnetic screwdriver, loosen the screw on the impaired mezzanine card.
e. Using the #1 magnetic screwdriver, gently lift the impaired mezzanine card directly out of the
socket and set it aside.
f. Remove the replacement mezzanine card from the antistatic shipping bag and align it to the
inside face of the controller module.
g. Gently align the replacement mezzanine card into place.
h. Using the #1 magnetic screwdriver, insert and tighten the screws on the face of the controller
module and on the mezzanine card.
Do not apply force when tightening the screw on the mezzanine card; you might
crack it.
i. Insert any SFP or QSFP modules that were removed from the impaired mezzanine card to the
replacement mezzanine card.
3. To install a mezzanine card:
4. You install a new mezzanine card if your system does not have one.
a. Using the #1 magnetic screwdriver, remove the screws from the face of the controller module and
the faceplate covering the mezzanine card slot, and set them aside safely on the magnet.
b. Remove the mezzanine card from the antistatic shipping bag and align it to the inside face of the
controller module.
c. Gently align the mezzanine card into place.
d. Using the #1 magnetic screwdriver, insert and tighten the screws on the face of the controller
module and on the mezzanine card.
Do not apply force when tightening the screw on the mezzanine card; you might
crack it.
== Step 4: Reinstall the controller module
After you replace a component within the controller module, you must reinstall the controller module in the
system chassis and boot it.
1. Close the controller module cover and tighten the thumbscrew.
